3-Compartment PTV Unit in Cargo Van with ADA

Start from this plan Download the plan sheet (JPEG)

PLAN VIEW · DIMENSIONS REMOVED FROM THE PUBLIC SHEETHLE ENGINEERING · WAKARUSA, IN

Ford Transit

Platform · van

Prisoner transport

Vehicle type

≈ 21 ft

Length · approx., typical for this chassis

PTV-139

Plan ID · quote it when you call

Dimensions are removed from the public drawing. Every unit is built to the customer's program; this plan is a starting point.

Ask sales for a fully dimensioned sheet

Budget range · typical for this vehicle type

$110,000 – $350,000

Typical range for recent HLE units, from the lowest sold to the highest quoted. Larger or more heavily equipped units run above it; your number comes with the proposal.

Vehicle, body and HLE-supplied equipment. Customer-furnished equipment itemized separately, no markup.

Line	On the budget
Platform and length	Ford Transit · ≈ 21 ft (approx.)
Major equipment	Itemized, HLE-supplied or customer-furnished
Access and power	Itemized
Budget	One-pager with line items, for a grant budget
